AC Centrifugal Radial Fan Motorized Impeller BASSF 160-60 is highly efficient and compact structure.
Current(A): 0, 6
Capacitor(µF): 5
Sound Pressure Level(dB(A)): 65
| Manufacturer: | Bahcivan (BVN) |
| Model: | BASSF 160-60 |
| Country of origin: | Turkey |
| Speed Control | Optional Controller |
| Insulation Class | Class B, Class F |
| Standard | EN 60335-2-80, EN 60335 |
| Frequency (Hz) | 50 |
| Applications | Duct fans, Centrifugal Fans, Machines Cooling and Boilers, Elevator Motor Cooling, Yacht Air Conditioning, Electric Board Cooling, Laboratories, Residential and Industrial Areas |
| Features | High Static Pressure, Laminar Air Flow, Low Noise Level, Powerful Design, High Efficiency |
| Material | Galvanized Sheet Steel |
| Voltage (V) | 230 |
| Speed (d/d) | 2630 |
| Air Flow (m3/h) | 600 |
| Power (Kw) | 150 |
| Weight (Kg) | 2.1 |
