IR Box Camera DH-HAC-HFW1100RN-VF
Supplied by
National Fire Fighting Manufacturing Company
IR box camera is high speed, long distance and have real-time transmission.
Specification:
Image Sensor: 1/2.9" 1Megapixel CMOS
Effective Pixels: 1280(H)×720(V)
Electronic Shutter: 1/60s~1/100,000s
Video Frame Rate: 30fps@720P
Synchronization: Internal
Min. Illumination: 0.01Lux@F1.2(AGC ON), 0Lux IR on
Video Output: 1-channel BNC HDCVI high denition video output
Noise Reduction: 2D/3D
Lens Type: Manual / Fixed Iris
Power Consumption: Max 5W
Working Environment: -30°C~+60°C / Less than 95%RH (no condensation)
Transmission Distance: Over 500m via 75-3 coaxial cable
Specifications
- Manufacturer:
- National Fire Fighting Manufacturing Company
- Model:
- DH-HAC-HFW1100RN-VF
- Country of origin:
- UAE
- Power Supply
- DC12V
- Resolution
- 25/30fps@720P
- Day/ Night (Camera Features) ICR
- AWB, BLC, AGC, 2D-DNR
- IP
- IP66
- Pixels
- 1
- User Interface
- Auto(ICR), AWB, AGC, BLC
- Focal Length
- 2.7~12mm
- Mount Type
- 14
- IR Range
- 30m
- Dimensions
- 90.4mm×213mm
- Weight
- 0.52kg
