euroceil Translucent Stretch Ceilings
Supplied by
Euroceil Stretch Ceiling
Design to create tranquil spaces, euroceil Translucent Stretch Ceilings allows evenly diffused illumination over large areas. Its ease of installation lets you create vast, seamless ceiling and lighting solutions. You can even alter moods with dimming controls for the illumination.
KEY FEATURES:
- Vast Seamless Span Upto 5 Metres Width
- Allows Evenly Diffused Illumination
- LED Backlighting with Custom LUX Levels
- Alter moods with Dimmable Controls for illumination
Visit our website for more info - http://www.euroceil.com/translucent.html
Specifications
- Manufacturer:
- Renolit
- Country of origin:
- Germany
- Colours
- 8 colours available, (Refer Website)
- Thickness
- 0.15mm to 0.2mm
- Weight
- Approx 200 gms/sq.m
- Breaking Strength
- 185 kg/cm2 (Length-wise), 220 kg/cm2 (Width-wise)
- Elongation
- 210% (Length-wise), 305% (Width-wise)
- Hardness
- 93.5 Shore A
- Light transmittance
- Approx 30%
- Relative Humidity < 65%
- 0.30 GR/H M2 mm
- Relative Humidity > 65%
- 0.45 GR/H M2 mm
- Dimensional Stability
- -5 deg Celsius to +55 deg Celsius
- Thermal Co-effecient
- 0.16 cal/m H C
- Fire Safety Norms
- B1/B2 in accordance with DIN 4102-1
- Acoustic Properties
- Reverberation times at 125/ 250/ 500/ 1000/ 2000 Hertz reduce from 1.5s to 0.7s with designed perforations and insulation
- Recycling Properties
- 100 % Recyclable
- Resistive Properties
- Anti-Bacterial, Anti-Fungal, Anti-Static, Impermeable to Water & Steam, Insensitive to X-rays & Chemicals, Flame Retardant, Non-Flammable, Self-Extinguishing, Energy Saving
- Boxing Material
- 25mm Plywood, 19mm Plywood
- Boxing Depth (For LEDs)
- 100 - 150 mm
- Boxing Conditions
- Airtight, ACP sheet or Internal painting with Enamel White Matte finish
- Boxing Suspension
- Framed or Thread Rods
