AC Rectangular in Line Duct Fans BDKF 60-30
Supplied by:
Meaptashi
AC Rectangular in Line Duct Fans BDKF 60-30 is developed and manufactured for high performance, trouble-free, and direct-to-duct operations.
Dimensions:
- A: 300
- B: 600
- C: 650
- D: 620
- E: 320
- F: 650
- G: 350
Power(W): 147
Current(A): 0,66
Capacitor(μF): 6
Sound Pressure Level(dB(A)): 70
Specifications
| Manufacturer: | Bahcivan (BVN) |
| Model: | BDKF 60-30 |
| Country of origin: | Turkey |
| Speed Control | Optional Controller |
| Insulation Class | Class B |
| Standard | EN 60335-1, EN 60335-2-80 |
| Frequency (Hz) | 50 |
| Applications | Residential, Commercial, Industrial |
| Material | Galvanized Sheet Steel |
| Voltage (V) | 230 |
| Features | High Performance, Trouble Free, Direct to Duct Operation |
| Air Flow (m3/h) | 1850 |
| Weight (Kg) | 29 |
| Speed (d/d) | 1440 |
